Monoprice HDMI Extender Over Single CAT6 (TCP/IP) - 100 Meters (328 Feet) With IR Support, HDCP 1.1 - Blackbird Series
Customize
Blackbird HDMI Extender over Single 100m CAT6 (TCP/IP) with IR Support The Monoprice BlackbirdTM HDMI Extender can transmit HDMI video to distances up to 328 feet (100 meters) over a single Cat6 Ethernet cable. It provides a bandwidth of 6.75Gbps and supports 1080p video resolutions, 12-bit per channel Deep Color, and 48kHz LPCM digital audio. It features an IR blaster which gives you the ability to transmit infrared remote control signals, allowing for truly remote control of your equipment. Extend up to 328ft: This extender can transmit HDMI video to distances up to 328 feet (100 meters) over a single standard Cat6 coaxial cable. IR Control: The bi-directional IR blaster allows you to control your video source device using its IR remote control from the remote location or to control the display from the source location. Compatibility: This extender carries High Speed HDMI signals at resolutions up to 1080p, making it compatible with DVD players, Blu-ray DiscTM players, gaming consoles, and more. Features • Supports the HDCP 1.1 standard • Supports video resolutions up to 1920x1080p • Supports 12-bits/channel (36-bits total) Deep Color • Supports high-definition audio, including 48kHz LPCM digital audio • Provides 6.75Gbps bandwidth • Equalizes and recovers incoming TMDS data • IR blaster transmits IR signals from the remote location to the HDMI source device
- Provides 6.75Gbps bandwidth.
- Supports high-definition audio, including 48kHz LPCM digital audio.
- Supports 12-bits/channel (36-bits total) deep color.
- Supports video resolutions up to 1920x1080p.
Specifications:
| Materials & Construction | |
| Color | Black |
| Product Details | |
| Compatible Devices | DVD Player |
| Connector Type | HDMI |
| Item model number | 116048 |
| Specific Uses For Product | DVD Player |
| Sizing & Dimensions | |
| Height | 1.5 inches |
| Length | 8.7 inches |
| Product Dimensions | 8.7 x 5.6 x 1.5 inches |
| Weight | 1 pounds |
| Width | 5.6 inches |
| Technical Specifications | |
| Audio Support | 48kHz LPCM |
| Bandwidth | 6.75Gbps |
| Deep Color | 12-bits/channel |
| IR Control | Bi-directional IR blaster |
| Max Resolution | 1920x1080p |
| Proprietary Features | Equalizes and recovers incoming TMDS data |
