Addon-Networking SFP+ Transceiver Module, LC Multi-Mode (SFPP-10G-SR-AO)
Customize
Napatech SFPP-10G-SR Compatible 10GBase-SR SFP+ Transceiver (MMF, 850nm, 300m, LC, DOM). A Napatech SFP+ transceiver that operates at 850nm over multi-mode fiber, with a maximum reach of 300m connected via a LC connector. This Napatech compatible SFP+ transceiver has been programmed, uniquely serialized, and data-traffic and application tested to ensure it is 100% compliant and functional. The SFP+ transceiver will initialize and perform identically to Napatech's transceiver and is built to meet or exceed Napatech's specifications, and comply with MSA (Multi-Source Agreement) standards. The actual part shipped may have a different part number, but will be functionally identical and 100% compatible. Trade Agreements Act (TAA) versions of this part are available. ADDON NAPATECH SFPP-10G-SR COMPATIBLE TAA COMPLIANT 10GBASE-SR SFP+ TRANSCEIVER(MMF, 850NM, 300M, LC, DOM)
- RoHS compliant and lead-free
- Single 3.3V power supply and low power dissipation <0.8W
- Distance up to 300m on 50/125um MMF (OM3)
- VCSEL transmitter and PIN receiver
- Excellent ESD protection
- Metal with lower EMI
- Support hot-pluggable
- Duplex LC connector
Specifications:
| Materials & Construction | |
| Construction Material | Metal housing |
| EMI Shielding | Yes |
| ESD Protection | Excellent |
| Product Details | |
| Is Discontinued By Manufacturer | No |
| Item model number | SFPP-10G-SR-AO |
| Operating System | PC |
| Series | SFPP-10G-SR-AO |
| Sizing & Dimensions | |
| Height | 1.2 inches |
| Length | 4.75 inches |
| Product Dimensions | 4.75 x 2.75 x 1.2 inches |
| Weight | 5.6 ounces |
| Width | 2.75 inches |
| Technical Specifications | |
| Connector | Duplex LC |
| DOM | Supported |
| Hot-Pluggable | Supported |
| Maximum Distance | 300m |
| Power Dissipation | <0.8W |
| Power Supply | Single 3.3V |
| Transmitter / Receiver | VCSEL transmitter and PIN receiver |
| Wavelength | 850nm |
